Incoloy 800 Chemical composition:
Alloy | % | Ni | Cr | Fe | C | Mn | Si | Cu | S | Al | Ti | P |
Incoloy 800 | Min. | 30 | 19 | balance | 0.15 | 0.15 | ||||||
Max. | 35 | 23 | 0.10 | 1.5 | 1 | 0.75 | 0.015 | 0.60 | 0.60 | 0.03 |
Incoloy 800 Physical properties
Density | 7.95 g/cm3 |
Melting point | 1357-1385 ℃ |
Minimum mechanical properties in the room temperature
Status | Tensile strength | Yield strength | Elongation |
annealed treatment | 520 | 205 | 30 |
800 Characteristic:
Excellent resisto, superb oxidation resistance and carbonification resistance at high temperature and good corrosion resistance in water.
Incoloy 800 Application range and field：
Used in heat exchangers, piping system, vaporization equipments, reactors, parts and components used in furnace, ammonia nitrogen effluents radiator etc.
